Bike Geometry

• Bottom bracket drop [mm]: 72 mm,69 mm,67 mm
• Chain stay length [mm]: 415 mm
• Fork offset [mm]: 373 mm
• Fork total length [mm]: 50 mm
• Head tube angle: 71.5 degrees,72 degrees,72.5 degrees,71 degrees
• Head tube length [mm]: 155 mm,175 mm,195 mm,220 mm,135 mm
• Reach [mm]: 375 mm,380 mm,388 mm,395 mm,371 mm
• Stack [mm]: 557 mm,575 mm,594 mm,618 mm,536 mm
• Seat tube angle: 74 degrees,73.5 degrees,73 degrees,72.5 degrees,74.5 degrees
• Seat tube length [mm]: 490 mm,520 mm,550 mm,580 mm,460 mm
• Top tube length [mm]: 535 mm,550 mm,570 mm,590 mm,520 mm
• Wheelbase [mm]: 999 mm,1006 mm,1021 mm,1031 mm,993 mm

Drivetrain

• Cassette Teeth: 11-34T
• Crankset Teeth: 50-34T
• Crankset Type: double
• Number Of Gears: 24
• Bottom Bracket Description: Shimano, PressFit, BB71-41B
• Cassette Description: Shimano, Cassette, CS-R8101-12, MICRO SPLINE
• Chain Description: Shimano, Cadena, 106 CN-M7100 12s
• Crankset Description: Shimano, Ultegra R8150
• Derailleur FrontDescription: Shimano, Down Swing, Ultegra Di2 R8150 Brazed-On
• Derailleur Rear Description: Shimano, Ultegra, Ultegra Di2 R8150, 12s
• Gear Description: Shimano, Derailleur
• Pedal Description: VP, Flat, 335 Clips&Strap
• Shifter Left Description: Shimano, Shift-brake lever, Ultegra ST-R8170
• Shifter Right Description: Shimano, Shift-brake lever, Ultegra ST-R8170

Frame and more

• Framesize Convection: S,M,L,XL,XS
• Max loadable weight (KG): 110 kg
• Front Fork Type: Non Suspension
• Front Fork Description: Lapierre, Pulsium Disc thru axle
• Frame Description: Carbón, Hombre

Handlebar and Saddle

• Handgrip Description: Lapierre
• Handlebar Description: Lapierre, Drop bar, Alloy, Drop: 130 mm, Reach: 80 mm
• Headset Description: Acros, Integrated, AIX-532 IS52/28,6 - IS52/40
• Saddle Description: Fizik, Race, Aliante R5 150mm
• Seatpost Description: Lapierre, Non Suspension, Alloy, Ø: 27.2 mm, L: 350 mm
• Stem Description: Lapierre, internal routing, Ø: 31.8 mm, L: 80 mm

Sistema de frenos

• Brake Rear Mount: Flat Mount
• Brake Front Description: Shimano, Freno de disco hidráulico, Ultegra R8170, 160 mm
• Brake Rear Description: Shimano, Freno de disco hidráulico, Ultegra R8170, 160 mm

Wheels and wheel components

• Wheelset Material: Aluminio
• Tamaño de la rueda en pul: 28
• Tyre Description: Schwalbe, ONE Performance TLE, 67EPI, 28-622
• Tyre Rear Description: Schwalbe, ONE Performance TLE, 67EPI
• Wheelset Description: DT Swiss, ER1600 SPLINE 700x22c, 23mm height, AXDR driver, Centerlock
• Wheelset Rear Description: DT Swiss, ER1600 Spline 23 DB, ER1600 SPLINE 700x22c, 23mm height, AXDR driver, Centerlock
• Wheelsize Description: 28, 28
