Bike Geometry


Bottom bracket drop [mm]: 25 mm
Chain stay length [mm]: 460 mm
Fork offset [mm]: 550 mm
Fork total length [mm]: 44 mm
Head tube angle: 65 degrees
Head tube length [mm]: 160 mm,110 mm,120 mm,140 mm
Reach [mm]: 495 mm,430 mm,450 mm,470 mm
Stack [mm]: 651 mm,603 mm,615 mm,633 mm
Seat tube angle: 76 degrees
Seat tube length [mm]: 490 mm,390 mm,430 mm,460 mm
Top tube length [mm]: 660 mm,583 mm,606 mm,630 mm
Wheelbase [mm]: 1291 mm,1211 mm,1230 mm,1257 mm


Drivetrain


Cassette Teeth: 11-48T
Crank Arm length: 160
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 10
Cassette Description: Shimano, Cassette, CUES CS-LG300-10, HG
Chain Description: Shimano, Cadena, CUES LG500 9/10/11s
Crankset Description: Samox, EC40-F13-ISIS + E13 Helix Core steel chainring 55CL
Derailleur Rear Description: Shimano, CUES U6000 10/11s Shadow+
Gear Description: Shimano, Derailleur
Pedal Description: XLC, by VP
Shifter Left Description: Shimano, Triggershift, CUES U6000 10s
Shifter Right Description: Shimano, Triggershift, CUES SL-U6000-10R


E-bike components


Battery Capacity: 600 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Powertube Horizontal 600Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, Kiox 300
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: XL,S,M,L
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 140 mm
Front Fork Description: Rockshox, Psylo Silver R 15x110 29" 140 mm
Frame Description: HIGH, Aluminio, Hombre
Shock Description: Lapierre, Shock 185x50 mm Trunnion/15x8 mm


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Aluminio
Handlebar Rise: 15,30
Handlebar Width: 760 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 170 mm,130 mm,150 mm
Stem Length: 50 mm,45 mm
Handgrip Description: Lapierre, grips large diameter
Handlebar Description: Lapierre, Flat bar, Thirty One 6061DB, Rise: 30 mm, Ø: 31.8 mm
Headset Description: Acros, Semi-integrated, Integrated ZS56/ZS56 Block Lock
Saddle Description: Selle Royal, MTB, Vivo
Seatpost Description: JD, Dropperpost, YSP18, Ø: 31.6 mm, travel: 170 mm + Shimano lever
Stem Description: Lapierre, Not Adjustable, Thirty One alloy, 0°, Ø: 31.8 mm, L: 50 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, M4100 4 pistons, 203 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, M4100 2 pistons, 203 mm
Brake Lever Description: Shimano, BL-M4100
Brake Rotor Description: Shimano, SM-RT30 203 mm, Centerlock


Wheels and wheel components


Tamaño de la rueda en pul: 29
Hub Front Description: Shimano, TC500, boost 15x110, 32H Centerlock
Hub Rear Description: Shimano, TC500, boost 12x148, 32H Centerlock, HG driver
Rim Description: Ryde, Disc30 32H, 30-622 Black Anodized
Rim Rear Description: Ryde, Disc30 32H, 30-622 Black Anodized
Tyre Description: Continental, Kryptotal F Enduro Soft, 60-622
Tyre Rear Description: Continental, Xynotal R Enduro Soft
Wheelsize Description: 29, 29

Bike Geometry


Bottom bracket drop [mm]: 25 mm
Chain stay length [mm]: 460 mm
Fork offset [mm]: 550 mm
Fork total length [mm]: 44 mm
Head tube angle: 65 degrees
Head tube length [mm]: 110 mm,120 mm,140 mm,160 mm
Reach [mm]: 430 mm,450 mm,470 mm,495 mm
Stack [mm]: 603 mm,615 mm,633 mm,651 mm
Seat tube angle: 76 degrees
Seat tube length [mm]: 390 mm,430 mm,460 mm,490 mm
Top tube length [mm]: 583 mm,606 mm,630 mm,660 mm
Wheelbase [mm]: 1211 mm,1230 mm,1257 mm,1291 mm


Drivetrain


Cassette Teeth: 11-50T
Crank Arm length: 160
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 11
Cassette Description: Shimano, Cassette, CUES CS-LG400-11, HG
Chain Description: Shimano, Cadena, CUES LG500 9/10/11s
Crankset Description: E Thirteen, Helix Core + E13 Helix Core steel chainring 55CL
Derailleur Rear Description: Shimano, CUES U6000 10/11s Shadow+
Gear Description: Shimano, Derailleur
Pedal Description: XLC, by VP
Shifter Left Description: Shimano, Triggershift, CUES U6000 11s
Shifter Right Description: Shimano, Triggershift, CUES SL-U6000-11R


E-bike components


Battery Capacity: 800 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Powertube Horizontal 800Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, Kiox 300
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 140 mm
Front Fork Description: Rockshox, Psylo Silver RC 15x110 29" 140 mm
Frame Description: HIGH, Aluminio, Hombre
Shock Description: Lapierre, Shock 185x50 mm Trunnion/15x8 mm


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Aluminio
Handlebar Rise: 15,30
Handlebar Width: 760 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 130 mm,150 mm,170 mm
Stem Length: 45 mm,50 mm
Handgrip Description: Lapierre, grips small diameter
Handlebar Description: Lapierre, Flat bar, Thirty One 6061DB, Rise: 15 mm, Ø: 31.8 mm
Headset Description: Acros, Semi-integrated, Integrated ZS56/ZS56 Block Lock
Saddle Description: Selle Royal, MTB, Vivo
Seatpost Description: JD, Dropperpost, YSP18, Ø: 31.6 mm, travel: 130 mm + Shimano lever
Stem Description: Lapierre, Not Adjustable, Thirty One alloy, 0°, Ø: 31.8 mm, L: 45 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, M4100 4 pistons, 203 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, M4100 2 pistons, 203 mm
Brake Lever Description: Shimano, BL-M4100
Brake Rotor Description: Shimano, SM-RT30 203 mm, Centerlock


Wheels and wheel components


Tamaño de la rueda en pul: 29
Hub Front Description: Shimano, TC500, boost 15x110, 32H Centerlock
Hub Rear Description: Shimano, TC500, boost 12x148, 32H Centerlock, HG driver
Rim Description: Ryde, Disc30 32H, 30-622 Black Anodized
Rim Rear Description: Ryde, Disc30 32H, 30-622 Black Anodized
Tyre Description: Continental, Kryptotal F Enduro Soft, 60-622
Tyre Rear Description: Continental, Xynotal R Enduro Soft
Wheelsize Description: 29, 29

Bike Geometry


Bottom bracket drop [mm]: 30 mm
Chain stay length [mm]: 460 mm
Fork offset [mm]: 585 mm
Fork total length [mm]: 44 mm
Head tube angle: 65 degrees,64.5 degrees
Head tube length [mm]: 110 mm,130 mm,150 mm
Reach [mm]: 455 mm,475 mm,500 mm,433 mm
Stack [mm]: 641 mm,659 mm,678 mm,638 mm
Seat tube angle: 76.5 degrees
Seat tube length [mm]: 430 mm,460 mm,490 mm,390 mm
Top tube length [mm]: 609 mm,633 mm,663 mm,586 mm
Wheelbase [mm]: 1248 mm,1276 mm,1311 mm,1231 mm


Drivetrain


Cassette Teeth: 11-50T
Crank Arm length: 160
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 11
Cassette Description: Shimano, Cassette, CUES CS-LG400-11, HG
Chain Description: Shimano, Cadena, CUES LG500 9/10/11s
Crankset Description: E Thirteen, Helix Core + E13 Helix Core steel chainring 55CL
Derailleur Rear Description: Shimano, CUES U6000 10/11s Shadow+
Gear Description: Shimano, Derailleur
Pedal Description: XLC, by VP
Shifter Left Description: Shimano, Triggershift, CUES U6000 11s
Shifter Right Description: Shimano, Triggershift, CUES SL-U6000-11R


E-bike components


Battery Capacity: 800 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Powertube Horizontal 800Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, Kiox 300
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: M,L,XL,S
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 170 mm
Front Fork Description: Rockshox, Domain Gold Isolator R 15x110 29" 170 mm
Frame Description: HIGH, Aluminio, Hombre
Shock Description: Lapierre, Shock 205x60 mm Trunnion/30x8 mm


Handlebar and Saddle


Handlebar Diameter: 35 mm
Handlebar Material: Aluminio
Handlebar Rise: 30
Handlebar Width: 800 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 130 mm,150 mm,170 mm
Stem Length: 35 mm,45 mm
Handgrip Description: Lapierre, grips small diameter
Handlebar Description: Lapierre, Flat bar, Thirty Five Alloy 6061DB, Rise: 30 mm, Ø: 35 mm
Headset Description: Acros, Semi-integrated, Integrated ZS56/ZS56 Block Lock
Saddle Description: Selle Royal, MTB, Vivo
Seatpost Description: JD, Dropperpost, YSP18, Ø: 31.6 mm, travel: 130 mm + Shimano lever
Stem Description: Lapierre, Not Adjustable, Thirty Five alloy 0°, Ø: 35 mm, L: 35 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, M4100 4 pistons, 203 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, M4100 4 pistons, 203 mm
Brake Lever Description: Shimano, BL-M4100
Brake Rotor Description: Shimano, SM-RT30 203 mm, Centerlock


Wheels and wheel components


Hub Front Description: Shimano, TC500, boost 15x110, 32H Centerlock
Hub Rear Description: Shimano, TC500, boost 12x148, 32H Centerlock, HG driver
Rim Description: Ryde, Disc30 32H, 30-622 Black Anodized
Rim Rear Description: Ryde, Disc35 32H, 35-684 Black Anodized
Tyre Description: Continental, Kryptotal F Enduro Soft, 60-622
Tyre Rear Description: Continental, Kryptotal R Enduro Soft
Wheelsize Description: 29, 27.5

Bike Geometry


Bottom bracket drop [mm]: 30 mm
Chain stay length [mm]: 460 mm
Fork offset [mm]: 585 mm
Fork total length [mm]: 44 mm
Head tube angle: 64.5 degrees,65 degrees
Head tube length [mm]: 110 mm,130 mm,150 mm
Reach [mm]: 433 mm,455 mm,475 mm,500 mm
Stack [mm]: 638 mm,641 mm,659 mm,678 mm
Seat tube angle: 76.5 degrees
Seat tube length [mm]: 390 mm,430 mm,460 mm,490 mm
Top tube length [mm]: 586 mm,609 mm,633 mm,663 mm
Wheelbase [mm]: 1231 mm,1248 mm,1276 mm,1311 mm


Drivetrain


Cassette Teeth: 10-52T
Crank Arm length: 160
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 12
Cassette Description: Sram, Cassette, XS1270 T-TYPE 12s, XD
Chain Description: Sram, Cadena, GX T-TYPE 12s
Crankset Description: E Thirteen, Helix Core + SRAM XX T-TYPE 55CL
Derailleur Rear Description: Sram, S1000 Eagle AXS T-TYPE 12s
Gear Description: Sram, Derailleur
Pedal Description: XLC, by VP
Shifter Left Description: Sram, Triggershift, AXS Pod 12s
Shifter Right Description: Sram, Triggershift, AXS Pod Controller 12s


E-bike components


Battery Capacity: 800 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Powertube Horizontal 800Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, Kiox 300
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 170 mm
Front Fork Description: Rockshox, ZEB Base RUSH RC 29" 15x110 DebonAir 170 mm
Frame Description: HIGH, Aluminio, Hombre
Shock Description: Rockshox, Deluxe Select R 205x60 mm Trunnion/30x8 mm


Handlebar and Saddle


Handlebar Diameter: 35 mm
Handlebar Material: Aluminio
Handlebar Rise: 30
Handlebar Width: 800 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 130 mm,150 mm,170 mm
Stem Length: 35 mm,45 mm
Handgrip Description: Lapierre, grips small diameter
Handlebar Description: Lapierre, Flat bar, Thirty Five Alloy 6061DB, Rise: 30 mm, Ø: 35 mm
Headset Description: Acros, Semi-integrated, Integrated ZS56/ZS56 Block Lock
Saddle Description: Selle Royal, MTB, Terra Aidon X5 145mm S-Alloy Mobius
Seatpost Description: JD, Dropperpost, YSP18, Ø: 31.6 mm, travel: 130 mm + Shimano lever
Stem Description: Lapierre, Not Adjustable, Thirty Five alloy 0°, Ø: 35 mm, L: 35 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Sram, Freno de disco hidráulico, DB8 Stealth 4 pistons, 220 mm
Brake Rear Description: Sram, Freno de disco hidráulico, DB8 Stealth 4 pistons, 200 mm
Brake Lever Description: Sram, DB8 Stealth-BL
Brake Rotor Description: Sram, HS2 220 / 200 mm, 6 bolt Disc


Wheels and wheel components


Wheelset Material: Aluminio
Tamaño de la rueda en pul: 27
Tyre Description: Continental, Kryptotal F Enduro Soft, 60-622
Tyre Rear Description: Continental, Kryptotal R Enduro Soft
Wheelset Description: Lapierre, eAM+ Alloy 32H, front: 622x33 J-bend Tubeless Ready
Wheelset Rear Description: Lapierre, eAM+ Alloy 32H, 584x35 J-bend Tubeless ready
Wheelsize Description: 29, 27.5

Bike Geometry


Bottom bracket drop [mm]: 30 mm
Chain stay length [mm]: 460 mm
Fork offset [mm]: 585 mm
Fork total length [mm]: 44 mm
Head tube angle: 64.5 degrees,65 degrees
Head tube length [mm]: 110 mm,130 mm,150 mm
Reach [mm]: 433 mm,455 mm,475 mm,500 mm
Stack [mm]: 638 mm,641 mm,659 mm,678 mm
Seat tube angle: 76.5 degrees
Seat tube length [mm]: 390 mm,430 mm,460 mm,490 mm
Top tube length [mm]: 586 mm,609 mm,633 mm,663 mm
Wheelbase [mm]: 1231 mm,1248 mm,1276 mm,1311 mm


Drivetrain


Cassette Teeth: 10-52T
Crank Arm length: 160
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 12
Cassette Description: Sram, Cassette, XS1275 T-TYPE 12s, XD
Chain Description: Sram, Cadena, GX T-TYPE 12s
Crankset Description: E Thirteen, Helix Core + SRAM XX T-TYPE 55CL
Derailleur Rear Description: Sram, GX Eagle AXS T-TYPE 12s
Gear Description: Sram, Derailleur
Pedal Description: XLC, by VP
Shifter Left Description: Sram, Triggershift, AXS Pod 12s
Shifter Right Description: Sram, Triggershift, AXS Pod Controller 12s


E-bike components


Battery Capacity: 800 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Powertube Horizontal 800Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, Kiox 300
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 170 mm
Front Fork Description: FOX Factory, 38 Float Performance Elite GRIP X 15x110 29" 170 mm
Frame Description: HIGH, Aluminio, Hombre
Shock Description: FOX Factory, Float X Performance Elite 205x60 mm Trunnion/30x8 mm


Handlebar and Saddle


Handlebar Diameter: 35 mm
Handlebar Material: Aluminio
Handlebar Rise: 30
Handlebar Width: 800 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 125 mm,150 mm,170 mm,200 mm
Stem Length: 35 mm,45 mm
Handgrip Description: Lapierre, grips small diameter
Handlebar Description: Lapierre, Flat bar, Thirty Five Alloy 6061DB, Rise: 30 mm, Ø: 35 mm
Headset Description: Acros, Semi-integrated, Integrated ZS56/ZS56 Block Lock
Saddle Description: Selle Royal, MTB, Terra Aidon X5 145mm S-Alloy Mobius
Seatpost Description: JD, Dropperpost, YSI05, Ø: 31.6 mm, travel: 125 mm
Stem Description: Lapierre, Not Adjustable, Thirty Five alloy 0°, Ø: 35 mm, L: 35 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Sram, Freno de disco hidráulico, Maven Bronze 4 pistons, 220 mm
Brake Rear Description: Sram, Freno de disco hidráulico, Maven Bronze 4 pistons, 200 mm
Brake Lever Description: Sram, Maven Bronze-BL
Brake Rotor Description: Sram, HS2 220 / 200 mm, 6 bolt Disc


Wheels and wheel components


Wheelset Material: Aluminio
Tamaño de la rueda en pul: 27
Tyre Description: Continental, Kryptotal F Enduro Soft, 60-622
Tyre Rear Description: Continental, Kryptotal R Enduro Soft
Wheelset Description: Lapierre, eAM+ Alloy 32H, front: 622x33 J-bend Tubeless Ready
Wheelset Rear Description: Lapierre, eAM+ Alloy 32H, 584x35 J-bend Tubeless ready
Wheelsize Description: 29, 27.5

Bike Geometry


Bottom bracket drop [mm]: 10 mm
Chain stay length [mm]: 440 mm
Fork offset [mm]: 600 mm
Fork total length [mm]: 44 mm
Head tube angle: 64 degrees
Head tube length [mm]: 110 mm,120 mm,130 mm,140 mm
Reach [mm]: 435 mm,460 mm,480 mm,505 mm
Stack [mm]: 629 mm,638 mm,647 mm,656 mm
Seat tube angle: 77 degrees
Seat tube length [mm]: 390 mm,400 mm,430 mm,460 mm
Top tube length [mm]: 580 mm,607 mm,629 mm,656 mm
Wheelbase [mm]: 1225 mm,1255 mm,1279 mm,1308 mm


Drivetrain


Cassette Teeth: 10-51T
Crank Arm length: 160,165
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 12
Cassette Description: Shimano, Cassette, Deore XT CS-M8100-12, MICRO SPLINE
Chain Description: Shimano, Cadena, XT CN-M8100 12s
Chain Guide Description: Lapierre, 1x
Crankset Description: E Thirteen, E-spec+ Race Carbon + E13 E-spec Alloy chainring
Derailleur Rear Description: Shimano, XTR, XTR 12s Shadow +
Gear Description: Shimano, Derailleur
Pedal Description: VP, VPE-527
Shifter Right Description: Shimano, Triggershift, XTR SL-M9100


E-bike components


Battery Capacity: 800 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Powerpack battery 800Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, KIOX 300 + Mini Remote
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 170 mm
Front Fork Description: FOX Factory, Float 38 Factory FIT4 170 mm / 3-position lever
Frame Description: HIGH, Carbón, Hombre
Shock Description: FOX Factory, Float X Factory, 2-Pos Lever, LSC, LV Evol, 205x65 mm


Handlebar and Saddle


Handlebar Diameter: 35 mm
Handlebar Material: Aluminio
Handlebar Rise: 30
Handlebar Width: 800 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 125 mm,150 mm,170 mm
Stem Length: 35 mm,45 mm
Handgrip Description: Lapierre, Grips Anodized, small diameter
Handlebar Description: Lapierre, Flat bar, Thirty Five Alloy 6061DB, Rise: 30 mm, Ø: 35 mm
Headset Description: Acros, Semi-integrated, Top: Integrated routing / Bottom: Block lock
Saddle Description: Fizik, MTB, Terra Aidon X3 145mm
Seatpost Description: Limotec, Dropperpost, A1 Light dropper, Ø: 31.6 mm, travel: 125 mm
Stem Description: Lapierre, Thirty Five Alloy 0°, Ø: 35 mm, L: 35 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, XTR 4 pistons, BR-M9120, 203 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, XTR 4 pistons, BR-M9120, 203 mm
Brake Lever Description: Shimano, XTR BL-M9100
Brake Rotor Description: Shimano, RTMT800 / RTEM810 with magnet, 203 mm, Centerlock


Wheels and wheel components


Wheelset Material: Aluminio
Tamaño de la rueda en pul: 28
Tyre Description: Schwalbe, MAGIC MARY Evo, 67TPI, Super Trail, Addix Ultra soft, TR, 62-622
Tyre Rear Description: Schwalbe, BIG BETTY, 67TPI, Super Trail, Addix soft, TR
Wheelset Description: Mavic, E-DEEMAX S 30 29" 15x110 mm
Wheelset Rear Description: Mavic, E-DEEMAX S 35 27,5" Micro Spline driver 12x148 mm
Wheelsize Description: 29, 27.5

Bike Geometry


Bottom bracket drop [mm]: 30 mm
Chain stay length [mm]: 435 mm,440 mm,445 mm
Fork offset [mm]: 550 mm
Fork total length [mm]: 44 mm
Head tube angle: 65 degrees
Head tube length [mm]: 110 mm,120 mm,130 mm,140 mm
Reach [mm]: 435 mm,460 mm,480 mm,505 mm
Stack [mm]: 610 mm,619 mm,628 mm,637 mm
Seat tube angle: 77 degrees
Seat tube length [mm]: 370 mm,400 mm,430 mm,460 mm
Top tube length [mm]: 576 mm,603 mm,625 mm,652 mm
Wheelbase [mm]: 1188 mm,1217 mm,1246 mm,1280 mm


Drivetrain


Cassette Teeth: 10-51T
Crank Arm length: 165,170
Crankset Teeth: 32T
Crankset Type: single
Number Of Gears: 12
Cassette Description: Shimano, Cassette, Deore CS-M6100-12, MICRO SPLINE
Chain Description: Shimano, Cadena, Deore M6100 12s
Chain Guide Description: Lapierre, 1x
Crankset Description: Rotor, E-Kapic Crank + Rotor Ride 60 Alloy chainring
Derailleur Rear Description: Shimano, XT, XT M8100, 12s Shadow +
Gear Description: Shimano, Derailleur
Pedal Description: VP, VPE-527
Shifter Right Description: Shimano, Triggershift, SLX SL-M7100-R Rapidfire


E-bike components


Battery Capacity: 430 Wh
Battery Location: Downtube
Motor Torque [nm]: 60 Nm
Motor Location: Center
Battery Description: Fazua, 430Wh battery pack
Charger Description: Fazua, 3A90 Charger
Display Description: Fazua, Ring control remote
Motor Description: Fazua, RIDE 60


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 140 mm
Front Fork Description: Rockshox, Lyrik Select+ Charger 3 RC2 140 mm
Frame Description: HIGH, Carbón, Hombre
Shock Description: Rockshox, Super Deluxe Select+ 210x55 mm


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Aluminio
Handlebar Rise: 15
Handlebar Width: 780 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 125 mm,150 mm,170 mm
Stem Length: 40 mm,45 mm
Handgrip Description: Lapierre, Grips Anodized, small diameter
Handlebar Description: Lapierre, Flat bar, Alloy 6061DB, Rise: 15 mm, Ø: 31.8 mm
Headset Description: Acros, Integrated, integrated headset with Block Lock
Saddle Description: Fizik, MTB, Terra Aidon X5 145mm
Seatpost Description: Lapierre, Dropperpost, Dropper, Ø: 31.6 mm, travel: 125 mm
Stem Description: Lapierre, Alloy CNC, Ø: 31.8 mm, L: 40 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, SLX M7120 4 pistons, 203 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, SLX M7120 4 pistons, 203 mm
Brake Lever Description: Shimano, SLX M7120-BL
Brake Rotor Description: Shimano, MT800 203mm, Centerlock


Wheels and wheel components


Wheelset Material: Aluminio
Tamaño de la rueda en pul: 29
Tyre Description: Maxxis, Assegai 3C MaxxTerra, EXO+, 29x2.5 WT, 60TPI, TR
Tyre Rear Description: Maxxis, Minion DHR II, EXO, 29x2.4 WT, 60TPI, TR
Wheelset Description: Lapierre, eAM+ Alloy 28H, Straight Pull, 15x110 mm, Tubeless Ready
Wheelset Rear Description: Lapierre, eAM+ Alloy 28H, Straight Pull, 12x148 mm, Tubeless Ready
Wheelsize Description: 29, 29

Bike Geometry


Bottom bracket drop [mm]: 10 mm
Chain stay length [mm]: 440 mm
Fork offset [mm]: 600 mm
Fork total length [mm]: 44 mm
Head tube angle: 64 degrees
Head tube length [mm]: 110 mm,120 mm,130 mm,140 mm
Reach [mm]: 435 mm,460 mm,480 mm,505 mm
Stack [mm]: 629 mm,638 mm,647 mm,656 mm
Seat tube angle: 77 degrees
Seat tube length [mm]: 390 mm,400 mm,430 mm,460 mm
Top tube length [mm]: 580 mm,607 mm,629 mm,656 mm
Wheelbase [mm]: 1225 mm,1255 mm,1279 mm,1308 mm


Drivetrain


Cassette Teeth: 10-52T
Crank Arm length: 160,165
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 12
Cassette Description: Sram, Cassette, XS1295 T-TYPE-12, XD
Chain Description: Sram, Cadena, XO T-TYPE Powerlock 12s
Chain Guide Description: Lapierre, 1x
Crankset Description: E Thirteen, E-spec+ Race Carbon + SRAM XX T-TYPE
Derailleur Rear Description: Sram, X01 Eagle AXS, X0 Eagle AXS T-TYPE, 12s
Gear Description: Sram, Derailleur
Pedal Description: VP, VPE-527
Shifter Right Description: Sram, Triggershift, AXS Pod Ultimate 12s


E-bike components


Battery Capacity: 800 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Powerpack battery 800Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, KIOX 300 + Mini Remote
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 170 mm
Front Fork Description: Rockshox, ZEB Ultimate Charger 3 RC2 170 mm
Frame Description: HIGH, Carbón, Hombre
Shock Description: Rockshox, Vivid Air 2 Ultimate, 2-Pos Lever, 205x65mm Trunnion


Handlebar and Saddle


Handlebar Diameter: 35 mm
Handlebar Material: Aluminio
Handlebar Rise: 30
Handlebar Width: 800 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 125 mm,150 mm,170 mm
Stem Length: 35 mm,45 mm
Handgrip Description: Lapierre, Grips Anodized, small diameter
Handlebar Description: Renthal, Flat bar, Fatbar, Rise: 30 mm, Ø: 35 mm
Headset Description: Acros, Semi-integrated, Top: Integrated routing / Bottom: Block lock
Saddle Description: Fizik, Terra Aidon X3 KIUM 145mm
Seatpost Description: Sram, Dropperpost, Reverb AXS, Ø: 31.6mm, travel: 125 mm
Stem Description: Renthal, Apex, Ø: 35 mm, L: 33 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Sram, Freno de disco hidráulico, Code Ultimate Stealth 4 pistons, 220 mm
Brake Rear Description: Sram, Freno de disco hidráulico, Code Ultimate Stealth 4 pistons, 200 mm
Brake Lever Description: Sram, Code Ultimate Stealth-BL
Brake Rotor Description: Sram, Centerline 220 / 200 mm, 6 bolt Disc


Wheels and wheel components


Wheelset Material: Carbón
Tamaño de la rueda en pul: 28
Tyre Description: Schwalbe, MAGIC MARY Evo, 67TPI, Super Trail, Addix Ultra soft, TR, 62-622
Tyre Rear Description: Schwalbe, BIG BETTY, 67TPI, Super Trail, Addix soft, TR
Wheelset Description: Lapierre, eAM+ carbon, 622x30, J-bend Tubeless ready, 15x110 mm
Wheelset Rear Description: Lapierre, eAM+ carbon, 584x33 J-bend Tubeless ready, 12x148 mm
Wheelsize Description: 29, 27.5

Bike Geometry


Bottom bracket drop [mm]: 30 mm
Chain stay length [mm]: 435 mm,440 mm,445 mm
Fork offset [mm]: 550 mm
Fork total length [mm]: 44 mm
Head tube angle: 65 degrees
Head tube length [mm]: 110 mm,120 mm,130 mm,140 mm
Reach [mm]: 435 mm,460 mm,480 mm,505 mm
Stack [mm]: 610 mm,619 mm,628 mm,637 mm
Seat tube angle: 77 degrees
Seat tube length [mm]: 370 mm,400 mm,430 mm,460 mm
Top tube length [mm]: 576 mm,603 mm,625 mm,652 mm
Wheelbase [mm]: 1188 mm,1217 mm,1246 mm,1280 mm


Drivetrain


Cassette Teeth: 10-51T
Crank Arm length: 165,170
Crankset Teeth: 32T
Crankset Type: single
Number Of Gears: 12
Cassette Description: Shimano, Cassette, Deore XT CS-M8100-12, MICRO SPLINE
Chain Description: Shimano, Cadena, SLX M7100 12s
Chain Guide Description: Lapierre, 1x
Crankset Description: Rotor, E-Kapic Crank + Rotor Ride 60 Alloy chainring
Derailleur Rear Description: Shimano, XT, XT M8100, 12s Shadow +
Gear Description: Shimano, Derailleur
Pedal Description: VP, VPE-527
Shifter Right Description: Shimano, Triggershift, SLX SL-M7100


E-bike components


Battery Capacity: 430 Wh
Battery Location: Downtube
Motor Torque [nm]: 60 Nm
Motor Location: Center
Battery Description: Fazua, 430Wh battery pack
Charger Description: Fazua, 3A90 Charger
Display Description: Fazua, Ring control remote
Motor Description: Fazua, RIDE 60


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 140 mm
Front Fork Description: Rockshox, Pike Ultimate Charger 3 RC2 140 mm
Frame Description: HIGH, Carbón, Hombre
Shock Description: Rockshox, Deluxe Ultimate 210x55 mm


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Carbón
Handlebar Rise: 20
Handlebar Width: 800 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 125 mm,150 mm,170 mm
Stem Length: 40 mm,45 mm
Handgrip Description: Lapierre, Grips Anodized, small diameter
Handlebar Description: Renthal, Flat bar, Fatbar Carbon, Rise: 20 mm, Ø: 31.8 mm
Headset Description: Acros, Integrated, integrated headset with Block Lock'
Saddle Description: Fizik, MTB, Terra Aidon X5 145mm
Seatpost Description: Lapierre, Dropperpost, Light Dropper, Ø: 31.6 mm, travel: 125 mm
Stem Description: Lapierre, Alloy CNC, Ø: 31.8 mm, L: 40 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, XT M8120 4 pistons, 203 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, XT M8120 4 pistons, 203 mm
Brake Lever Description: Shimano, XT M8120-BL
Brake Rotor Description: Shimano, MT800 203 mm, Centerlock


Wheels and wheel components


Wheelset Material: Carbón
Tamaño de la rueda en pul: 29
Tyre Description: Maxxis, Assegai 3C MaxxTerra, EXO+, 29x2.5 WT, 60TPI, TR
Tyre Rear Description: Maxxis, Minion DHR II, EXO, 29x2.4 WT, 60TPI, TR
Wheelset Description: Lapierre, eAM+ Carbon, 15x110 mm, Micro Spline driver, Tubeless Ready
Wheelset Rear Description: Lapierre, eAM+ Carbon, 12x148 mm, Micro Spline driver, Tubeless Ready
Wheelsize Description: 29, 29

Bike Geometry


Bottom bracket drop [mm]: 30 mm
Chain stay length [mm]: 460 mm
Fork offset [mm]: 585 mm
Fork total length [mm]: 44 mm
Head tube angle: 64.5 degrees,65 degrees
Head tube length [mm]: 110 mm,130 mm,150 mm
Reach [mm]: 433 mm,455 mm,475 mm,500 mm
Stack [mm]: 638 mm,641 mm,659 mm,678 mm
Seat tube angle: 76.5 degrees
Seat tube length [mm]: 390 mm,430 mm,460 mm,490 mm
Top tube length [mm]: 586 mm,609 mm,633 mm,663 mm
Wheelbase [mm]: 1231 mm,1248 mm,1276 mm,1311 mm


Drivetrain


Cassette Teeth: 10-52T
Crank Arm length: 160
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 12
Cassette Description: Sram, Cassette, XS1275 T-TYPE 12s, XD
Chain Description: Sram, Cadena, GX T-TYPE 12s
Crankset Description: E Thirteen, Helix Core + SRAM XX T-TYPE 55CL
Derailleur Rear Description: Sram, GX Eagle AXS T-TYPE 12s
Gear Description: Sram, Derailleur
Pedal Description: XLC, by VP
Shifter Left Description: Sram, Triggershift, AXS Pod 12s
Shifter Right Description: Sram, Triggershift, AXS Pod Controller 12s


E-bike components


Battery Capacity: 800 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Powertube Horizontal 800Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, Kiox 300
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 170 mm
Front Fork Description: Rockshox, ZEB Ultimate Charger 3.1 RC2 15x110 29" 170 mm
Frame Description: HIGH, Aluminio, Hombre
Shock Description: Rockshox, Super Deluxe Ultimate RC2T 205x60mm Trunnion/30x8mm


Handlebar and Saddle


Handlebar Diameter: 35 mm
Handlebar Material: Aluminio
Handlebar Rise: 30
Handlebar Width: 800 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 125 mm,150 mm,170 mm,200 mm
Stem Length: 35 mm,45 mm
Handgrip Description: Lapierre, grips small diameter
Handlebar Description: Lapierre, Flat bar, Thirty Five Alloy 6061DB, Rise: 30 mm, Ø: 35 mm
Headset Description: Acros, Semi-integrated, Integrated ZS56/ZS56 Block Lock
Saddle Description: Selle Royal, MTB, Terra Ridon X3 145mm Kium Mobius
Seatpost Description: JD, Dropperpost, YSI05, Ø: 31.6 mm, travel: 125 mm
Stem Description: Lapierre, Not Adjustable, Thirty Five alloy 0°, Ø: 35 mm, L: 35 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Sram, Freno de disco hidráulico, Maven Silver 4 pistons, 220 mm
Brake Rear Description: Sram, Freno de disco hidráulico, Maven Silver 4 pistons, 200 mm
Brake Lever Description: Sram, Maven Silver-BL
Brake Rotor Description: Sram, HS2 220 / 200 mm, 6 bolt Disc


Wheels and wheel components


Wheelset Material: Carbón
Tamaño de la rueda en pul: 27
Tyre Description: Continental, Kryptotal F Enduro Soft, 60-622
Tyre Rear Description: Continental, Kryptotal R Enduro Soft
Wheelset Description: DT Swiss, HX1501 Spline One 622x30, 15x110 mm
Wheelset Rear Description: DT Swiss, HX1501 Spline One 584x35, 12x148 mm, XD Driver
Wheelsize Description: 29, 27.5

Bike Geometry


Bottom bracket drop [mm]: 30 mm
Chain stay length [mm]: 460 mm
Fork offset [mm]: 585 mm
Fork total length [mm]: 44 mm
Head tube angle: 64.5 degrees,65 degrees
Head tube length [mm]: 102 mm,110 mm,130 mm,150 mm
Reach [mm]: 435 mm,455 mm,475 mm,500 mm
Stack [mm]: 631 mm,641 mm,659 mm,678 mm
Seat tube angle: 76.5 degrees
Seat tube length [mm]: 390 mm,430 mm,470 mm,510 mm
Top tube length [mm]: 587 mm,609 mm,633 mm,663 mm
Wheelbase [mm]: 1230 mm,1248 mm,1276 mm,1310 mm


Drivetrain


Cassette Teeth: 10-52T
Crank Arm length: 160,165
Crankset Teeth: 34T
Crankset Type: single
Number Of Gears: 12
Cassette Description: Sram, Cassette, XG1275 Eagle 12s, XD
Chain Description: Sram, Cadena, XX1 Black Eagle Powerlock 12s
Crankset Description: E Thirteen, E-spec+ Race Carbon + SRAM Eagle steel ring
Derailleur Rear Description: Sram, X01 Eagle, X01 Eagle, 12s
Gear Description: Sram, Derailleur
Pedal Description: VP, VPE-527
Shifter Right Description: Sram, Triggershift, X01 Single click Eagle 12s


E-bike components


Battery Capacity: 750 Wh
Battery Location: Downtube
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, Intube battery 750Wh
Charger Description: Bosch, Quick Charger, Charger 4A
Display Description: Bosch, KIOX 300 + LED Remote
Motor Description: Bosch, Performance line CX


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 170 mm
Front Fork Description: FOX Factory, 38 Factory 29'' 15x110 / 3-position lever 170 mm
Frame Description: HIGH, Aluminio, Hombre
Shock Description: FOX Factory, X Factory 230x60 mm 2-position lever


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Carbón
Handlebar Rise: 19
Handlebar Width: 785 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 125 mm,150 mm,170 mm
Stem Length: 40 mm,45 mm
Handgrip Description: Lapierre, Anodized, small diameter
Handlebar Description: Race Face, Flat bar, SixC carbon, Rise: 19 mm, Ø: 31.8 mm
Headset Description: Fsa, Integrated, NO.55R/57E, Black Anodized, 1-1/8"-1.5"
Saddle Description: Fizik, MTB, Terra Aidon X3 145mm
Seatpost Description: JD, Dropperpost, Dropper, Ø: 31.6 mm, travel: 125 mm + MMX Remote
Stem Description: Lapierre, Alloy CNC, Ø: 31.8 mm, L: 40 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Sram, Freno de disco hidráulico, Code RSC 4 pistons, 220 mm
Brake Rear Description: Sram, Freno de disco hidráulico, Code RSC 4 pistons, 200 mm
Brake Lever Description: Sram, Code RSC-BL
Brake Rotor Description: Sram, Centerline 220 / 200 mm, 6 bolt Disc


Wheels and wheel components


Wheelset Material: Aluminio
Tamaño de la rueda en pul: 29
Tyre Description: Schwalbe, MAGIC MARY Evo, 67TPI, Super Trail, Addix Ultra soft, 62-622
Tyre Rear Description: Schwalbe, BIG BETTY, 67TPI, Super Trail, Addix soft, TR
Wheelset Description: Mavic, E-DEEMAX S 30 29"
Wheelset Rear Description: Mavic, E-DEEMAX S 35 27,5" XD driver
Wheelsize Description: 29, 27.5

Batería


Bosch InTube 800 Wh

Capacidad de la batería

800 Wh


Cargador


Bosch Charger 4A 220-240V


Marca de la batería


Bosch


Motor


Bosch Performance Line CX


Número de niveles de asistencia


0


Pantalla


Bosch Kiox 300 + LED Remote


Par del motor (nm)


85 Nm


Sistema de bicicleta eléctrica


Bosch


freno delantero


Shimano Hydraulic Disc brake Deore BR-MT420, 4 pistons, 203 mm


Freno trasero


Shimano Hydraulic Disc brake Deore BR-MT420, 4 pistons, 203 mm


Manillar


XLC Riser Bar MTB CAT4, Dia. 31.8 mm, Rise: 20 mm, backsweep 9°


Marca de los puños


XLC


Pedal


VP VPE-527 Alloy w/ Reflector


Sillín


Selle Royal MTB Vivo 1216HRN

Tija de sillín

Limotec Dropperpost Alpha 1 Dropper, Dia. 34.9 mm, Travel: 170 mm

Tipo de montaje de pata de cabra

KSA18


Tipo de transmisión


MTB Grip Set VLG-1751D2


Cadena


Shimano Deore CN-M6100 12s


Cambiador derecho


Shimano Triggershift Deore SL-M6100-IR, Rapidfire+


Cassette


Shimano Deore CS-M6100-12, MICRO SPLINE


Desviador trasero


Shimano Deore RD-M6100-SGS 12s, Shadow+


Juego de bielas


Miranda Crius ISIS Crankset + CR for Bosch BDU38, DM 165


Número de marchas


12


Transmisión


Shimano Derailleur


Amortiguador


FOX Factory FLOAT Performance, 2pos, Evol LV, 210x55mm


Horquilla delantera


FOX Factory 36 Float Rhythm, GRIP, E-Optimized, QR 160 mm


Recorrido


160 mm


Recorrido trasero


150 mm


Neumático


Continental Xynotal Trail Endurance, foldable skin SL 60-622


Rim


WTB ST i30 TCS 2.0 29" 32H


Tamaño de la rueda delantera


29


Tamaño de la rueda trasera


27.5


Tamaño del neumático ETRTO


60-622


Cuadro


HIGH Aluminium Uni


Material del cuadro


Aluminio


Peso máximo permitido


150 kg


Tamaño del cuadro


43 cm

Bike Geometry


Bottom bracket drop [mm]: 20 mm
Chain stay length [mm]: 455 mm
Fork total length [mm]: 44 mm
Head tube angle: 64.5 degrees
Head tube length [mm]: 130 mm,135 mm,140 mm
Reach [mm]: 408 mm,435 mm,468 mm,501 mm
Stack [mm]: 651 mm,656 mm,660 mm
Stand over height [mm]: 770 mm,760 mm
Seat tube angle: 75 degrees
Seat tube length [mm]: 405 mm,435 mm,465 mm,485 mm
Top tube length [mm]: 567 mm,594 mm,628 mm,662 mm
Wheelbase [mm]: 1206 mm,1233 mm,1268 mm,1303 mm


Drivetrain


Cassette Teeth: 10-51T
Crank Arm length: 160,165
Crankset Teeth: 36T
Crankset Type: single
Number Of Gears: 12
Pedal Inclusive: Si
Cassette Description: Shimano, SLX CS-M7100-12, MICRO SPLINE
Chain Description: Shimano, Cadena, Deore CN-M6100 12s
Chain Guide Description: Winning, WI-38L-95 Chainguide
Crankset Description: Miranda, Crius ISIS Crankset + Chainring for Bosch BDU38
Derailleur Hanger Description: Glory Wheel, UDH
Derailleur Rear Description: Shimano, SLX RD-M7100-SGS 12s, Shadow+
Gear Description: Shimano, Derailleur
Pedal Description: VP, VPE-527 Alloy w/ Reflector
Shifter Right Description: Shimano, Triggershift, Deore SL-M6100-R, Rapidfire+


E-bike components


Battery Capacity: 800 Wh
Battery Location: Powertube
Max Support Speed [km/h]: 25 km/h
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, InTube 800 Wh
Charger Description: Bosch, Charger 4A 220-240V
Display Description: Bosch, Kiox 300 + LED Remote
Motor Description: Bosch, Performance Line CX


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 135 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 160 mm
Travel Rear: 150 mm
Front Fork Description: Rockshox, Psylo Gold RC, Crown Adj, DebonAir 160 mm
Frame Description: High, Aluminio, Unisex
Shock Description: Rockshox, Deluxe Select+ RT 205x65mm, Trunnion, DebonAir+


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Aluminio
Handlebar Width: 780 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 125 mm,150 mm,170 mm
Stem Length: 35 mm
Handgrip Description: XLC, MTB Grip Set VLG-1751D2
Handlebar Description: Haibike, Flat bar, TheBar++ Dia. 31.8 mm
Headset Description: Acros, Semi-integrated, BlockLock 135° AZX-220-R4 ZS44/ZS56
Saddle Description: Prologo, Proxim W400 T2.0 153 mm
Seatpost Description: Limotec, Dropperpost, A1H Dropper, Dia. 34.9 mm, Travel: 125 mm
Stem Description: Haibike, The Stem++ Dia. 31.8 mm, L: 35 mm, A-Head


Lighting


Brake Light: No


Sistema de frenos


Brake Front Mount: Post Mount
Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, Deore BR-MT420, 4 pistons, resin pad, 203 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, Deore BR-MT420, 4 pistons, resin pad, 203 mm
Brake Lever Description: Shimano, BL-MT401
Brake Rotor Description: Shimano, SM-RT30 203 mm, Centerlock


Wheels and wheel components


Tamaño de la rueda en pul: 29
Hub Front Description: Shimano, HB-TC500-15-B 15x110 mm, 32H, Centerlock
Hub Rear Description: Shimano, FH-MT510-B 12x148 mm, 32H, Centerlock, MS
Rim Description: WTB, ST i30 TCS 2.0 29" 32H
Rim Rear Description: WTB, ST i35 TCS 2.0 27.5" 32H
Spoke Description: Sapim, Race Dia. 2.0, J-Bend
Tyre Description: Continental, Kryptotal-Fr, Trail Endurance, foldable skin SL, 60-622
Tyre Rear Description: Continental, Xynotal-Re, Trail Endurance, foldable skin SL
Wheelsize Description: 29, 27.5

Bike Geometry


Bottom bracket drop [mm]: 20 mm
Chain stay length [mm]: 455 mm
Fork offset [mm]: 580 mm
Fork total length [mm]: 44 mm
Head tube angle: 64.5 degrees
Head tube length [mm]: 130 mm,135 mm,140 mm
Reach [mm]: 435 mm,468 mm,501 mm,408 mm
Stack [mm]: 651 mm,656 mm,660 mm
Stand over height [mm]: 770 mm,760 mm
Seat tube angle: 75 degrees
Seat tube length [mm]: 435 mm,465 mm,485 mm,405 mm
Top tube length [mm]: 594 mm,628 mm,662 mm,567 mm
Wheelbase [mm]: 1233 mm,1268 mm,1303 mm,1206 mm


Drivetrain


Cassette Teeth: 11-50T
Crank Arm length: 160,165
Crankset Teeth: 36T
Crankset Type: single
Number Of Gears: 12
Pedal Inclusive: Si
Cassette Description: Sram, PG-1230 Eagle, HG
Chain Description: Sram, Cadena, SX Eagle 12s
Chain Guide Description: Winning, WI-38L-95 Chainguide
Crankset Description: Miranda, Crius ISIS CRNKS + SRAM CR T-Type Bosch DU38, DM
Derailleur Hanger Description: Glory Wheel, UDH
Derailleur Rear Description: Sram, NX Eagle 12s
Gear Description: Sram, Derailleur
Pedal Description: VP, VPE-527 Alloy w/ Reflector
Shifter Right Description: Sram, Triggershift, NX Eagle Single Click Trigger


E-bike components


Battery Capacity: 800 Wh
Battery Location: Powertube
Max Support Speed [km/h]: 25 km/h
Motor Torque [nm]: 85 Nm
Motor Location: Center
Battery Description: Bosch, InTube 800 Wh
Charger Description: Bosch, Charger 4A 220-240V
Display Description: Bosch, Purion 200
Motor Description: Bosch, Performance Line CX


Frame and more


Framesize Convection: M,L,XL,S
Max loadable weight (KG): 135 kg
Front Fork Type: Suspension
Suspension Type: Fully
Travel Front: 160 mm
Travel Rear: 150 mm
Front Fork Description: Rockshox, Psylo Gold RC, Crown Adj, DebonAir 160 mm
Frame Description: High, Aluminio, Unisex
Shock Description: Rockshox, Deluxe Select R 205x65mm, Trunnion, DebonAir


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Aluminio
Handlebar Width: 780 mm
Seatpost Material: Aluminio
Seatpost Travel (mm): 150 mm,170 mm,125 mm
Stem Length: 35 mm
Handgrip Description: XLC, MTB Grip Set VLG-1751D2
Handlebar Description: Haibike, Flat bar, TheBar++ Dia. 31.8 mm
Headset Description: Acros, Semi-integrated, BlockLock 135° AZX-220-R4 ZS44/ZS56
Saddle Description: Selle Royal, Vivo 1216HRN
Seatpost Description: Limotec, Dropperpost, A1H Dropper, Dia. 34.9 mm, Travel: 150 mm
Stem Description: Haibike, The Stem++ Dia. 31.8 mm, L: 35 mm, A-Head


Lighting


Brake Light: No


Sistema de frenos


Brake Front Mount: Post Mount
Brake Rear Mount: Post Mount
Brake Front Description: Tektro, Freno de disco hidráulico, TRP Slate EVO HD-M807, 4 pistons, 203 mm
Brake Rear Description: Tektro, Freno de disco hidráulico, TRP Slate EVO HD-M807, 4 pistons, 203 mm
Brake Lever Description: Tektro, TRP Slate EVO HD-M807-BL
Brake Rotor Description: Tektro, TRP RS01E 203 mm, 6 bolt Disc


Wheels and wheel components


Tamaño de la rueda en pul: 29
Hub Front Description: Haibike, The Hub++ Boost 15x110 mm, 32H, 6 bolt Disc
Hub Rear Description: Haibike, The Hub++ Boost 12x148 mm, 32H, 6 bolt Disc, HG
Rim Description: WTB, ST i30 TCS 2.0 29" 32H
Rim Rear Description: WTB, ST i35 TCS 2.0 27.5" 32H
Spoke Description: Sapim, Race Dia. 2.0, J-Bend
Tyre Description: Continental, Kryptotal-Fr, Trail Endurance, foldable skin SL, 60-622
Tyre Rear Description: Continental, Xynotal-Re, Trail Endurance, foldable skin SL
Wheelsize Description: 29, 27.5

Cuadro


Unisex Aluminium Uni


Material del cuadro


Aluminio


Peso máximo permitido


150 kg


Tamaño del cuadro


46 cm


Tipo de cuadro


Unisex


Neumático


Continental Xynotal Trail Endurance, foldable skin SL 60-622


Rim


WTB ST i30 TCS 2.0 29" 32H


Tamaño de la rueda delantera


29


Tamaño de la rueda trasera


27.5


Tamaño del neumático ETRTO


60-622


Amortiguador


Rockshox Deluxe Select R 210x55mm, DebonAir+


Horquilla delantera


Rockshox Psylo Silver RC, Crown Adjust, Solo Air, 160 mm


Recorrido


160 mm


Recorrido trasero


150 mm


Cadena


Sram SX Eagle 12s


Cambiador derecho


Sram Triggershift SX Eagle Trigger


Cassette


Sram PG-1210 Eagle, HG


Desviador trasero


Sram SX Eagle 12s


Juego de bielas


Miranda Crius ISIS Crankset + CR SRAM X-SYNC 2 Eagle DM 165


Número de marchas


12


Transmisión


Sram Derailleur


Batería


Bosch InTube 800 Wh


Capacidad de la batería


800 Wh


Cargador


Bosch Charger 4A 220-240V


Marca de la batería


Bosch


Motor


Bosch Performance Line CX


Número de niveles de asistencia


0


Pantalla


Bosch Kiox 300 + LED Remote


Par del motor (nm)


85 Nm


Sistema de bicicleta eléctrica


Bosch


freno delantero


Tektro Hydraulic Disc brake HD-M535, 4 pistons, resin pad, 203 mm


Freno trasero


Tektro Hydraulic Disc brake HD-M535, 4 pistons, resin pad, 203 mm


Manillar


XLC Riser Bar MTB CAT4, Dia. 31.8 mm, Rise: 20 mm, backsweep 9°


Marca de los puños


XLC


Pedal


VP VPE-527 Alloy w/ Reflector


Sillín


Selle Royal MTB Vivo 1216HRN


Tija de sillín


Limotec Dropperpost Alpha 1 Dropper, Dia. 34.9 mm, Travel: 200 mm


Tipo de montaje de pata de cabra


KSA18


Tipo de transmisión


MTB Grip Set VLG-1751D2
