Bike Geometry

• Bottom bracket drop [mm]: 30 mm
• Chain stay length [mm]: 460 mm
• Fork offset [mm]: 585 mm
• Fork total length [mm]: 44 mm
• Head tube angle: 64.5 degrees,65 degrees
• Head tube length [mm]: 102 mm,110 mm,130 mm,150 mm
• Reach [mm]: 435 mm,455 mm,475 mm,500 mm
• Stack [mm]: 631 mm,641 mm,659 mm,678 mm
• Seat tube angle: 76.5 degrees
• Seat tube length [mm]: 390 mm,430 mm,470 mm,510 mm
• Top tube length [mm]: 587 mm,609 mm,633 mm,663 mm
• Wheelbase [mm]: 1230 mm,1248 mm,1276 mm,1310 mm

Drivetrain

• Cassette Teeth: 10-52T
• Crank Arm length: 160,165
• Crankset Teeth: 34T
• Crankset Type: single
• Number Of Gears: 12
• Cassette Description: Sram, Cassette, XG1275 Eagle 12s, XD
• Chain Description: Sram, Cadena, XX1 Black Eagle Powerlock 12s
• Crankset Description: E Thirteen, E-spec+ Race Carbon + SRAM Eagle steel ring
• Derailleur Rear Description: Sram, X01 Eagle, X01 Eagle, 12s
• Gear Description: Sram, Derailleur
• Pedal Description: VP, VPE-527
• Shifter Right Description: Sram, Triggershift, X01 Single click Eagle 12s

E-bike components

• Battery Capacity: 750 Wh
• Battery Location: Downtube
• Motor Torque [nm]: 85 Nm
• Motor Location: Center
• Battery Description: Bosch, Intube battery 750Wh
• Charger Description: Bosch, Quick Charger, Charger 4A
• Display Description: Bosch, KIOX 300 + LED Remote
• Motor Description: Bosch, Performance line CX

Frame and more

• Framesize Convection: S,M,L,XL
• Max loadable weight (KG): 120 kg
• Front Fork Type: Suspension
• Suspension Type: Fully
• Travel Front: 170 mm
• Front Fork Description: FOX Factory, 38 Factory 29'' 15x110 / 3-position lever 170 mm
• Frame Description: HIGH, Aluminio, Hombre
• Shock Description: FOX Factory, X Factory 230x60 mm 2-position lever

Handlebar and Saddle

• Handlebar Diameter: 31.8 mm
• Handlebar Material: Carbón
• Handlebar Rise: 19
• Handlebar Width: 785 mm
• Seatpost Material: Aluminio
• Seatpost Travel (mm): 125 mm,150 mm,170 mm
• Stem Length: 40 mm,45 mm
• Handgrip Description: Lapierre, Anodized, small diameter
• Handlebar Description: Race Face, Flat bar, SixC carbon, Rise: 19 mm, Ø: 31.8 mm
• Headset Description: Fsa, Integrated, NO.55R/57E, Black Anodized, 1-1/8"-1.5"
• Saddle Description: Fizik, MTB, Terra Aidon X3 145mm
• Seatpost Description: JD, Dropperpost, Dropper, Ø: 31.6 mm, travel: 125 mm + MMX Remote
• Stem Description: Lapierre, Alloy CNC, Ø: 31.8 mm, L: 40 mm

Sistema de frenos

• Brake Rear Mount: Post Mount
• Brake Front Description: Sram, Freno de disco hidráulico, Code RSC 4 pistons, 220 mm
• Brake Rear Description: Sram, Freno de disco hidráulico, Code RSC 4 pistons, 200 mm
• Brake Lever Description: Sram, Code RSC-BL
• Brake Rotor Description: Sram, Centerline 220 / 200 mm, 6 bolt Disc

Wheels and wheel components

• Wheelset Material: Aluminio
• Tamaño de la rueda en pul: 29
• Tyre Description: Schwalbe, MAGIC MARY Evo, 67TPI, Super Trail, Addix Ultra soft, 62-622
• Tyre Rear Description: Schwalbe, BIG BETTY, 67TPI, Super Trail, Addix soft, TR
• Wheelset Description: Mavic, E-DEEMAX S 30 29"
• Wheelset Rear Description: Mavic, E-DEEMAX S 35 27,5" XD driver
• Wheelsize Description: 29, 27.5
