Bike Geometry

• Bottom bracket drop [mm]: 72 mm,69 mm,67 mm
• Chain stay length [mm]: 415 mm
• Fork offset [mm]: 378 mm
• Fork total length [mm]: 50 mm
• Head tube angle: 71 degrees,71.5 degrees,72 degrees,72.5 degrees
• Head tube length [mm]: 120 mm,135 mm,155 mm,175 mm,195 mm,215 mm
• Reach [mm]: 375 mm,379 mm,384 mm,389 mm,394 mm,400 mm
• Stack [mm]: 527 mm,541 mm,562 mm,579 mm,599 mm,618 mm
• Seat tube angle: 74.5 degrees,74 degrees,73.5 degrees,73 degrees,72.5 degrees
• Seat tube length [mm]: 440 mm,460 mm,490 mm,520 mm,550 mm,580 mm
• Top tube length [mm]: 521 mm,529 mm,545 mm,561 mm,577 mm,595 mm
• Wheelbase [mm]: 993 mm,1002 mm,1009 mm,1017 mm,1028 mm,1036 mm

Drivetrain

• Cassette Teeth: 10-36T
• Crankset Teeth: 46-33T
• Crankset Type: double
• Number Of Gears: 24
• Bottom Bracket Description: Sram, PressFit, DUB 86.5 Road
• Cassette Description: Sram, Cassette, XG1250 12s, XD
• Chain Description: Sram, Cadena, Rival 12s
• Crankset Description: Sram, Rival D1 DUB
• Derailleur FrontDescription: Sram, Rival ETAP AXS Brazed-On
• Derailleur Rear Description: Sram, Rival ETAP AXS, 12s
• Gear Description: Sram, Derailleur
• Pedal Description: VP, 335 Clips&Strap
• Shifter Left Description: Sram, Shift-brake lever, Rival ETAP AXS
• Shifter Right Description: Sram, Shift-brake lever, Rival ETAP AXS

Frame and more

• Framesize Convection: XS,S,M,L,XL,XXL
• Max loadable weight (KG): 110 kg
• Front Fork Type: Non Suspension
• Front Fork Description: Lapierre, Carbon UD SL
• Frame Description: Carbón, Hombre

Handlebar and Saddle

• Handgrip Description: Lapierre
• Handlebar Description: Lapierre, Drop bar, Alloy, Drop: 120 mm, Reach: 70 mm, Flare: 10°
• Headset Description: Acros, Integrated, Integrated
• Saddle Description: Fizik, Race, Aliante R5 150mm
• Seatpost Description: Lapierre, Non Suspension, Alloy, Ø: 27.2 mm, L: 350 mm, OFF: 0 mm
• Stem Description: Lapierre, Not Adjustable, internal routing, -10°, Ø: 31.8 mm, L: 80 mm

Sistema de frenos

• Brake Rear Mount: Flat Mount
• Brake Front Description: Sram, Freno de disco hidráulico, Rival ETAP AXS, 160 mm
• Brake Rear Description: Sram, Freno de disco hidráulico, Rival ETAP AXS, 140 mm

Wheels and wheel components

• Wheelset Material: Aluminio
• Tamaño de la rueda en pul: 28
• Tyre Description: Schwalbe, One Perf, RaceGuard, MicroSkin, TLE, 32-622
• Tyre Rear Description: Schwalbe, One Perf, RaceGuard, MicroSkin, TLE
• Wheelset Description: DT Swiss, E1800 Spline 30 mm, Tubeless compatible
• Wheelset Rear Description: DT Swiss, E1800 Spline 30 mm, Tubeless compatible, XD Driver
• Wheelsize Description: 28, 28
