Bike Geometry


Bottom bracket drop [mm]: 67 mm,62 mm
Chain stay length [mm]: 420 mm
Fork offset [mm]: 505 mm
Fork total length [mm]: 44 mm
Head tube angle: 68 degrees
Head tube length [mm]: 85 mm,90 mm,100 mm,110 mm
Reach [mm]: 410 mm,435 mm,455 mm,480 mm
Stack [mm]: 598 mm,597 mm,606 mm,616 mm
Seat tube angle: 74 degrees
Seat tube length [mm]: 390 mm,430 mm,470 mm,510 mm
Top tube length [mm]: 581 mm,606 mm,629 mm,657 mm
Wheelbase [mm]: 1086 mm,1114 mm,1138 mm,1167 mm


Drivetrain


Cassette Teeth: 10-51T
Crank Arm length: 170,175
Crankset Teeth: 32T
Crankset Type: single
Number Of Gears: 12
Bottom Bracket Description: Shimano, PressFit, MT800
Cassette Description: Shimano, Cassette, Deore CS-M6100-12, MICRO SPLINE
Chain Description: Shimano, Cadena, Deore M6100 12s
Crankset Description: Shimano, Deore FC-MT512
Derailleur Rear Description: Shimano, Deore 12s Shadow +
Gear Description: Shimano, Derailleur
Pedal Description: NW 91K Steel cage
Shifter Right Description: Shimano, Triggershift, Deore Rapidfire SL-M6100-IR


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Hardtail
Travel Front: 100 mm
Front Fork Description: Suntour, Raidon 32 RLR DS 15x110 29" 100 mm
Frame Description: HIGH, Carbón, Hombre


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Aluminio
Handlebar Width: 740 mm
Seatpost Material: Aluminio
Stem Length: 60 mm,70 mm,80 mm
Handgrip Description: Lapierre, Anodized, small diameter
Handlebar Description: Lapierre, Flat bar, Alloy 6061 Top flat, Ø: 31.8 mm
Headset Description: Fsa, Integrated, IS-2 /42/ACB 1-1/8''-1.5''
Saddle Description: Lapierre, MTB, XC Saddle
Seatpost Description: Lapierre, Non Suspension, Alloy, Ø: 27.2 mm, L: 400 mm, 400 mm
Stem Description: Lapierre, AL6061 Alloy, -6°, Ø: 31.8 mm, L: 60 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, MT401 2 pistons, 180 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, MT401 2 pistons, 160 mm
Brake Lever Description: Shimano, BL-MT401
Brake Rotor Description: Shimano, SM-RT64 180 / 160 mm, Centerlock


Wheels and wheel components


Tamaño de la rueda en pul: 29
Hub Front Description: Shimano, TC500, boost 15x110, 32H Centerlock
Hub Rear Description: Shimano, TC500, boost 12x148, 32H Centerlock, Microspline
Rim Description: Rodi, Tryp25 25x622, 32H Black Anodized
Rim Rear Description: Rodi, Tryp25 25x622, 32H Black Anodized
Tyre Description: Maxxis, Rekon Race EXO TR 2.35 60 TPI
Tyre Rear Description: Maxxis, Rekon Race EXO TR 2.35 60 TPI
Wheelsize Description: 29, 29

Bike Geometry


Bottom bracket drop [mm]: 65 mm,60 mm
Chain stay length [mm]: 428 mm
Fork offset [mm]: 505 mm
Fork total length [mm]: 44 mm
Head tube angle: 69 degrees,69.5 degrees
Head tube length [mm]: 90 mm,105 mm
Reach [mm]: 371 mm,390 mm,416 mm,437 mm
Stack [mm]: 584 mm,605 mm,600 mm,614 mm
Seat tube angle: 73 degrees
Seat tube length [mm]: 390 mm,430 mm,470 mm,510 mm
Top tube length [mm]: 550 mm,575 mm,600 mm,625 mm
Wheelbase [mm]: 1094 mm,1121 mm,1142 mm,1171 mm


Drivetrain


Cassette Teeth: 10-51T
Crank Arm length: 170,175
Crankset Teeth: 32T
Crankset Type: single
Number Of Gears: 12
Bottom Bracket Description: Shimano, PressFit, MT800 MTB 92
Cassette Description: Shimano, Cassette, Deore CS-M6100-12, MICRO SPLINE
Chain Description: Shimano, Cadena, Deore M6100 12s
Crankset Description: Shimano, Deore FC-MT512
Derailleur Rear Description: Shimano, Deore 12s Shadow +
Gear Description: Shimano, Derailleur
Pedal Description: NW 91K Steel cage
Shifter Right Description: Shimano, Triggershift, Deore Rapidfire SL-M6100-IR


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Suspension Type: Hardtail
Travel Front: 100 mm
Front Fork Description: Suntour, Raidon 32 RLR DS 15x110 29" 100 mm
Frame Description: HIGH, Aluminio, Hombre


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Aluminio
Handlebar Width: 720 mm
Seatpost Material: Aluminio
Stem Length: 60 mm,70 mm,80 mm
Handgrip Description: Lapierre, by Herrmans
Handlebar Description: Lapierre, Flat bar, Alloy 6061 Top flat, Ø: 31.8 mm
Headset Description: Fsa, Semi-integrated, Orbit Zero stack
Saddle Description: Lapierre, MTB, XC Saddle
Seatpost Description: Lapierre, Non Suspension, Alloy, Ø: 27.2 mm, L: 400 mm, 400 mm
Stem Description: Lapierre, 7050 Alloy, 7°, Ø: 31.8 mm, L: 60 mm


Sistema de frenos


Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, MT401 2 pistons, 180 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, MT401 2 pistons, 160 mm
Brake Lever Description: Shimano, BL-MT401
Brake Rotor Description: Shimano, SM-RT30 180 / 160 mm, Centerlock


Wheels and wheel components


Tamaño de la rueda en pul: 29
Hub Front Description: Shimano, TC500, boost 15x110, 32H Centerlock
Hub Rear Description: Shimano, TC500, boost 12x148, 32H Centerlock, Microspline
Rim Description: Rodi, Tryp25 25x622, 32H Black Anodized
Rim Rear Description: Rodi, Tryp25 25x622, 32H Black Anodized
Tyre Description: Maxxis, Rekon Race 2.25 60 TPI
Tyre Rear Description: Maxxis, Rekon Race 2.25 60 TPI
Wheelsize Description: 29, 29

Bike Geometry


Bottom bracket drop [mm]: 60 mm
Chain stay length [mm]: 450 mm
Fork offset [mm]: 509 mm
Fork total length [mm]: 46 mm
Head tube angle: 68 degrees
Head tube length [mm]: 105 mm,115 mm,125 mm,135 mm
Reach [mm]: 392 mm,409 mm,426 mm,443 mm
Stack [mm]: 613 mm,622 mm,632 mm,641 mm
Stand over height [mm]: 715 mm,735 mm,765 mm,780 mm
Seat tube angle: 73.5 degrees
Seat tube length [mm]: 400 mm,440 mm,480 mm,520 mm
Top tube length [mm]: 575 mm,595 mm,615 mm,635 mm
Wheelbase [mm]: 1112 mm,1133 mm,1154 mm,1175 mm


Drivetrain


Cassette Teeth: 10-51T
Crank Arm length: 170,175
Crankset Teeth: 32T
Crankset Type: single
Number Of Gears: 12
Pedal Inclusive: Si
Bottom Bracket Description: Shimano, BSA, Deore SM-BB52 68/73 mm, HOLLOWTECH II
Cassette Description: Shimano, Deore CS-M6100-12, MICRO SPLINE
Chain Description: Shimano, Deore CN-M6100 12s
Crankset Description: Shimano, FC-MT510-1, 2-Piece Crankset
Derailleur Hanger Description: Ghost, GRH-21bl black + Screws FRHG0004
Derailleur Rear Description: Shimano, Deore RD-M6100-SGS 12s, Shadow+
Gear Description: Shimano, Derailleur
Pedal Description: FPD, NW-91K steel cage black
Shifter Right Description: Shimano, Triggershift, Deore SL-M6100-R, Rapidfire+


Frame and more


Framesize Convection: S,M,L,XL
Max loadable weight (KG): 120 kg
Front Fork Type: Suspension
Type kickstand mount: KSA40
Suspension Type: Hardtail
Travel Front: 100 mm
Front Fork Description: Rockshox, Judy TK, Remote, QR, 100 mm
Frame Description: HIGH, Aluminio, Unisex


Handlebar and Saddle


Handlebar Diameter: 31.8 mm
Handlebar Material: Aluminio
Handlebar Rise: 0
Handlebar Width: 720 mm,740 mm,760 mm
Seatpost Material: Aluminio
Stem Length: 50 mm
Handgrip Description: Ghost, GND51 MTB GRIP VLG-1751D2
Handlebar Description: Ghost, Flat bar, Ground Fiftyone Dia. 31.8 mm, backsweep 9°
Headset Description: Glory Wheel, Semi-integrated, Strummer Headset, 1SI110 ZS44/ZS44
Saddle Description: Selle Italia, X-Base
Seatpost Description: Kalloy, Non Suspension, SP-DC1, Dia. 31.6 mm, L: 350 mm, 350 mm
Stem Description: Ghost, Ground Fiftyone Dia. 31.8 mm, L: 50 mm, A-Head


Sistema de frenos


Brake Front Mount: Post Mount
Brake Rear Mount: Post Mount
Brake Front Description: Shimano, Freno de disco hidráulico, BR-MT200, 2 pistons, resin pad, 180 mm
Brake Rear Description: Shimano, Freno de disco hidráulico, BR-MT200, 2 pistons, resin pad, 180 mm
Brake Lever Description: Shimano, BL-MT200
Brake Rotor Description: Shimano, SM-RT10 180 mm, Centerlock


Wheels and wheel components


Tamaño de la rueda en pul: 29
Hub Front Description: Shimano, HB-TX505, 32H, QR 100 mm, Centerlock
Hub Rear Description: Shimano, FH-MT401, 32H, QR 135 mm, Centerlock, MS
Rim Description: Rodi, Excalibur XC19 29", single eyelet, 32H
Rim Rear Description: Rodi, Excalibur XC19 29", single eyelet, 32H
Spoke Description: DT Swiss, FACTORY 2.0
Tyre Description: Schwalbe, Smart Sam K-Guard, 57-622
Tyre Rear Description: Schwalbe, Smart Sam K-Guard
Wheelsize Description: 29, 29
