Bike Geometry

• Bottom bracket drop [mm]: 71 mm,70 mm
• Chain stay length [mm]: 430 mm
• Fork offset [mm]: 425 mm
• Fork total length [mm]: 45 mm
• Head tube angle: 70.5 degrees,71 degrees,71.5 degrees
• Head tube length [mm]: 95 mm,115 mm,130 mm,150 mm,170 mm,195 mm
• Reach [mm]: 367 mm,373 mm,380 mm,386 mm,390 mm,398 mm
• Stack [mm]: 546 mm,567 mm,581 mm,601 mm,620 mm,644 mm
• Seat tube angle: 73.5 degrees,73 degrees,72.5 degrees
• Seat tube length [mm]: 440 mm,460 mm,490 mm,520 mm,550 mm,580 mm
• Top tube length [mm]: 529 mm,541 mm,552 mm,570 mm,585 mm,601 mm
• Wheelbase [mm]: 1007 mm,1016 mm,1027 mm,1036 mm,1045 mm,1062 mm

Drivetrain

• Cassette Teeth: 11-44T
• Crankset Teeth: 40T
• Crankset Type: single
• Number Of Gears: 12
• Bottom Bracket Description: Sram, PressFit, DUB 86.5 Road
• Cassette Description: Sram, Cassette, PG 1231 XPLR-12
• Chain Description: Sram, Cadena, Rival 12s
• Crankset Description: Sram, Rival DUB Wide
• Derailleur Rear Description: Sram, Rival XPLR AXS, 12s
• Gear Description: Sram, Derailleur
• Pedal Description: VP, 353 Clips&Strap
• Shifter Left Description: Sram, Triggershift, Rival ETAP AXS D1
• Shifter Right Description: Sram, Shift-brake lever, Rival ETAP AXS D1

Frame and more

• Framesize Convection: XS,S,M,L,XL,XXL
• Max loadable weight (KG): 110 kg
• Front Fork Type: Non Suspension
• Front Fork Description: Lapierre, Carbon UD SL
• Frame Description: Carbón, Hombre

Handlebar and Saddle

• Handgrip Description: Lapierre
• Handlebar Description: Lapierre, Drop bar, Alloy gravel bar, Drop: 130 mm, Reach: 80 mm
• Headset Description: Acros, Integrated, Integrated
• Saddle Description: Fizik, Gravel, Terra Argo X7 150mm
• Seatpost Description: Lapierre, Non Suspension, Alloy, Ø: 27.2 mm, L: 350 mm
• Stem Description: Lapierre, Not Adjustable, Alloy, internal routing, Ø: 31.8 mm, L: 80 mm

Sistema de frenos

• Brake Rear Mount: Flat Mount
• Brake Front Description: Sram, Freno de disco hidráulico, Rival XPLR AXS, 160 mm
• Brake Rear Description: Sram, Freno de disco hidráulico, Rival XPLR AXS, 160 mm

Wheels and wheel components

• Wheelset Material: Aluminio
• Tamaño de la rueda en pul: 28
• Tyre Description: WTB, Raddler TCS LIGHT 60TPI, 44-622
• Tyre Rear Description: WTB, Raddler TCS LIGHT 60TPI
• Wheelset Description: DT Swiss, GR1600 Spline 12x100 mm
• Wheelset Rear Description: DT Swiss, GR1600 Spline 12x142 mm
• Wheelsize Description: 28, 28
