Bike Geometry

• Bottom bracket drop [mm]: 20 mm
• Chain stay length [mm]: 455 mm
• Fork offset [mm]: 580 mm
• Fork total length [mm]: 44 mm
• Head tube angle: 64.5 degrees
• Head tube length [mm]: 130 mm,135 mm,140 mm
• Reach [mm]: 435 mm,468 mm,501 mm,408 mm
• Stack [mm]: 651 mm,656 mm,660 mm
• Stand over height [mm]: 770 mm,760 mm
• Seat tube angle: 75 degrees
• Seat tube length [mm]: 435 mm,465 mm,485 mm,405 mm
• Top tube length [mm]: 594 mm,628 mm,662 mm,567 mm
• Wheelbase [mm]: 1233 mm,1268 mm,1303 mm,1206 mm

Drivetrain

• Cassette Teeth: 11-50T
• Crank Arm length: 160,165
• Crankset Teeth: 36T
• Crankset Type: single
• Number Of Gears: 12
• Pedal Inclusive: Si
• Cassette Description: Sram, PG-1230 Eagle, HG
• Chain Description: Sram, Cadena, SX Eagle 12s
• Chain Guide Description: Winning, WI-38L-95 Chainguide
• Crankset Description: Miranda, Crius ISIS CRNKS + SRAM CR T-Type Bosch DU38, DM
• Derailleur Hanger Description: Glory Wheel, UDH
• Derailleur Rear Description: Sram, NX Eagle 12s
• Gear Description: Sram, Derailleur
• Pedal Description: VP, VPE-527 Alloy w/ Reflector
• Shifter Right Description: Sram, Triggershift, NX Eagle Single Click Trigger

E-bike components

• Battery Capacity: 800 Wh
• Battery Location: Powertube
• Max Support Speed [km/h]: 25 km/h
• Motor Torque [nm]: 85 Nm
• Motor Location: Center
• Battery Description: Bosch, InTube 800 Wh
• Charger Description: Bosch, Charger 4A 220-240V
• Display Description: Bosch, Purion 200
• Motor Description: Bosch, Performance Line CX

Frame and more

• Framesize Convection: M,L,XL,S
• Max loadable weight (KG): 135 kg
• Front Fork Type: Suspension
• Suspension Type: Fully
• Travel Front: 160 mm
• Travel Rear: 150 mm
• Front Fork Description: Rockshox, Psylo Gold RC, Crown Adj, DebonAir 160 mm
• Frame Description: High, Aluminio, Unisex
• Shock Description: Rockshox, Deluxe Select R 205x65mm, Trunnion, DebonAir

Handlebar and Saddle

• Handlebar Diameter: 31.8 mm
• Handlebar Material: Aluminio
• Handlebar Width: 780 mm
• Seatpost Material: Aluminio
• Seatpost Travel (mm): 150 mm,170 mm,125 mm
• Stem Length: 35 mm
• Handgrip Description: XLC, MTB Grip Set VLG-1751D2
• Handlebar Description: Haibike, Flat bar, TheBar++ Dia. 31.8 mm
• Headset Description: Acros, Semi-integrated, BlockLock 135° AZX-220-R4 ZS44/ZS56
• Saddle Description: Selle Royal, Vivo 1216HRN
• Seatpost Description: Limotec, Dropperpost, A1H Dropper, Dia. 34.9 mm, Travel: 150 mm
• Stem Description: Haibike, The Stem++ Dia. 31.8 mm, L: 35 mm, A-Head

Lighting

• Brake Light: No

Sistema de frenos

• Brake Front Mount: Post Mount
• Brake Rear Mount: Post Mount
• Brake Front Description: Tektro, Freno de disco hidráulico, TRP Slate EVO HD-M807, 4 pistons, 203 mm
• Brake Rear Description: Tektro, Freno de disco hidráulico, TRP Slate EVO HD-M807, 4 pistons, 203 mm
• Brake Lever Description: Tektro, TRP Slate EVO HD-M807-BL
• Brake Rotor Description: Tektro, TRP RS01E 203 mm, 6 bolt Disc

Wheels and wheel components

• Tamaño de la rueda en pul: 29
• Hub Front Description: Haibike, The Hub++ Boost 15x110 mm, 32H, 6 bolt Disc
• Hub Rear Description: Haibike, The Hub++ Boost 12x148 mm, 32H, 6 bolt Disc, HG
• Rim Description: WTB, ST i30 TCS 2.0 29" 32H
• Rim Rear Description: WTB, ST i35 TCS 2.0 27.5" 32H
• Spoke Description: Sapim, Race Dia. 2.0, J-Bend
• Tyre Description: Continental, Kryptotal-Fr, Trail Endurance, foldable skin SL, 60-622
• Tyre Rear Description: Continental, Xynotal-Re, Trail Endurance, foldable skin SL
• Wheelsize Description: 29, 27.5
