Bike Geometry

• Bottom bracket drop [mm]: 10 mm
• Chain stay length [mm]: 440 mm
• Fork offset [mm]: 600 mm
• Fork total length [mm]: 44 mm
• Head tube angle: 64 degrees
• Head tube length [mm]: 110 mm,120 mm,130 mm,140 mm
• Reach [mm]: 435 mm,460 mm,480 mm,505 mm
• Stack [mm]: 629 mm,638 mm,647 mm,656 mm
• Seat tube angle: 77 degrees
• Seat tube length [mm]: 390 mm,400 mm,430 mm,460 mm
• Top tube length [mm]: 580 mm,607 mm,629 mm,656 mm
• Wheelbase [mm]: 1225 mm,1255 mm,1279 mm,1308 mm

Drivetrain

• Cassette Teeth: 10-51T
• Crank Arm length: 160,165
• Crankset Teeth: 34T
• Crankset Type: single
• Number Of Gears: 12
• Cassette Description: Shimano, Cassette, Deore XT CS-M8100-12, MICRO SPLINE
• Chain Description: Shimano, Cadena, XT CN-M8100 12s
• Chain Guide Description: Lapierre, 1x
• Crankset Description: E Thirteen, E-spec+ Race Carbon + E13 E-spec Alloy chainring
• Derailleur Rear Description: Shimano, XTR, XTR 12s Shadow +
• Gear Description: Shimano, Derailleur
• Pedal Description: VP, VPE-527
• Shifter Right Description: Shimano, Triggershift, XTR SL-M9100

E-bike components

• Battery Capacity: 800 Wh
• Battery Location: Downtube
• Motor Torque [nm]: 85 Nm
• Motor Location: Center
• Battery Description: Bosch, Powerpack battery 800Wh
• Charger Description: Bosch, Quick Charger, Charger 4A
• Display Description: Bosch, KIOX 300 + Mini Remote
• Motor Description: Bosch, Performance line CX

Frame and more

• Framesize Convection: S,M,L,XL
• Max loadable weight (KG): 120 kg
• Front Fork Type: Suspension
• Suspension Type: Fully
• Travel Front: 170 mm
• Front Fork Description: FOX Factory, Float 38 Factory FIT4 170 mm / 3-position lever
• Frame Description: HIGH, Carbón, Hombre
• Shock Description: FOX Factory, Float X Factory, 2-Pos Lever, LSC, LV Evol, 205x65 mm

Handlebar and Saddle

• Handlebar Diameter: 35 mm
• Handlebar Material: Aluminio
• Handlebar Rise: 30
• Handlebar Width: 800 mm
• Seatpost Material: Aluminio
• Seatpost Travel (mm): 125 mm,150 mm,170 mm
• Stem Length: 35 mm,45 mm
• Handgrip Description: Lapierre, Grips Anodized, small diameter
• Handlebar Description: Lapierre, Flat bar, Thirty Five Alloy 6061DB, Rise: 30 mm, Ø: 35 mm
• Headset Description: Acros, Semi-integrated, Top: Integrated routing / Bottom: Block lock
• Saddle Description: Fizik, MTB, Terra Aidon X3 145mm
• Seatpost Description: Limotec, Dropperpost, A1 Light dropper, Ø: 31.6 mm, travel: 125 mm
• Stem Description: Lapierre, Thirty Five Alloy 0°, Ø: 35 mm, L: 35 mm

Sistema de frenos

• Brake Rear Mount: Post Mount
• Brake Front Description: Shimano, Freno de disco hidráulico, XTR 4 pistons, BR-M9120, 203 mm
• Brake Rear Description: Shimano, Freno de disco hidráulico, XTR 4 pistons, BR-M9120, 203 mm
• Brake Lever Description: Shimano, XTR BL-M9100
• Brake Rotor Description: Shimano, RTMT800 / RTEM810 with magnet, 203 mm, Centerlock

Wheels and wheel components

• Wheelset Material: Aluminio
• Tamaño de la rueda en pul: 28
• Tyre Description: Schwalbe, MAGIC MARY Evo, 67TPI, Super Trail, Addix Ultra soft, TR, 62-622
• Tyre Rear Description: Schwalbe, BIG BETTY, 67TPI, Super Trail, Addix soft, TR
• Wheelset Description: Mavic, E-DEEMAX S 30 29" 15x110 mm
• Wheelset Rear Description: Mavic, E-DEEMAX S 35 27,5" Micro Spline driver 12x148 mm
• Wheelsize Description: 29, 27.5
