Bike Geometry

• Bottom bracket drop [mm]: 67 mm
• Chain stay length [mm]: 405 mm
• Fork offset [mm]: 368 mm
• Fork total length [mm]: 50 mm
• Head tube angle: 72 degrees,73 degrees,74 degrees
• Head tube length [mm]: 105 mm,120 mm,140 mm,160 mm,180 mm
• Reach [mm]: 376 mm,383 mm,393 mm,403 mm,415 mm
• Stack [mm]: 501 mm,516 mm,538 mm,557 mm,580 mm
• Seat tube angle: 74 degrees,73.5 degrees
• Seat tube length [mm]: 440 mm,460 mm,490 mm,520 mm,550 mm
• Top tube length [mm]: 520 mm,531 mm,547 mm,568 mm,587 mm
• Wheelbase [mm]: 969 mm,981 mm,989 mm,1005 mm,1014 mm

Drivetrain

• Cassette Teeth: 10-33T
• Crankset Teeth: 48-35T
• Crankset Type: double
• Number Of Gears: 24
• Bottom Bracket Description: Sram, PressFit, DUB 86.5 Road
• Cassette Description: Sram, Cassette, XG-1270 12s, XD
• Chain Description: Sram, Cadena, Force 12s
• Crankset Description: Sram, Force D2 DUB
• Derailleur FrontDescription: Sram, Force ETAP AXS Braze-On
• Derailleur Rear Description: Sram, Force AXS, Force ETAP AXS Max, 12s
• Gear Description: Sram, Derailleur
• Pedal Description: VP, Flat, 335 Clips&Strap
• Shifter Left Description: Sram, Shift-brake lever, Force ETAP AXS
• Shifter Right Description: Sram, Shift-brake lever, Force ETAP AXS

Frame and more

• Framesize Convection: XS,S,M,L,XL
• Max loadable weight (KG): 110 kg
• Front Fork Type: Non Suspension
• Front Fork Description: Lapierre, Xelius SL Disc Thru axle UD Superlight
• Frame Description: Carbón, Hombre

Handlebar and Saddle

• Handgrip Description: Lapierre
• Handlebar Description: Lapierre, Drop bar, Combo UD carbon, -10°
• Headset Description: Acros, Integrated, Integrated + Xelius Acros Spacer
• Saddle Description: Fizik, Race, Argo Vento R5 140 mm
• Seatpost Description: Lapierre, Non Suspension, Carbon light, Ø: 27.2 mm, L: 350 mm
• Stem Description: Lapierre, integrated in handlebar

Sistema de frenos

• Brake Rear Mount: Flat Mount
• Brake Front Description: Sram, Freno de disco hidráulico, Force, 160 mm
• Brake Rear Description: Sram, Freno de disco hidráulico, Force, 140 mm

Wheels and wheel components

• Wheelset Material: Carbón
• Tamaño de la rueda en pul: 28
• Tyre Description: Continental, GP5000S TR Tubeless ready, 28-622
• Tyre Rear Description: Continental, GP5000S TR Tubeless ready
• Wheelset Description: Lapierre, Road Disc Carbon 700x21c, 38mm height, XDR driver, TR
• Wheelset Rear Description: Lapierre, Road Disc Carbon 700x21c, 38mm height, XDR driver, TR
• Wheelsize Description: 28, 28
