Bike Geometry

• Bottom bracket drop [mm]: 72 mm,69 mm,67 mm
• Chain stay length [mm]: 415 mm
• Fork offset [mm]: 373 mm
• Fork total length [mm]: 50 mm
• Head tube angle: 71 degrees,71.5 degrees,72 degrees,72.5 degrees
• Head tube length [mm]: 135 mm,155 mm,175 mm,195 mm,220 mm
• Reach [mm]: 371 mm,375 mm,380 mm,388 mm,395 mm
• Stack [mm]: 536 mm,557 mm,575 mm,594 mm,618 mm
• Seat tube angle: 74.5 degrees,74 degrees,73.5 degrees,73 degrees,72.5 degrees
• Seat tube length [mm]: 460 mm,490 mm,520 mm,550 mm,580 mm
• Top tube length [mm]: 520 mm,535 mm,550 mm,570 mm,590 mm
• Wheelbase [mm]: 993 mm,999 mm,1006 mm,1021 mm,1031 mm

Drivetrain

• Cassette Teeth: 10-36T
• Crankset Teeth: 46-33T
• Crankset Type: double
• Number Of Gears: 24
• Bottom Bracket Description: Sram, PressFit, DUB 86.5 Road
• Cassette Description: Sram, Cassette, XG1250 12s, XD
• Chain Description: Sram, Cadena, Rival 12s
• Crankset Description: Sram, Rival Dub
• Derailleur FrontDescription: Sram, Down Swing, Rival ETAP AXS Braze-On
• Derailleur Rear Description: Sram, Force AXS, Rival ETAP AXS Max, 12s
• Gear Description: Sram, Derailleur
• Pedal Description: VP, Flat, 335 Clips&Strap
• Shifter Left Description: Sram, Shift-brake lever, Rival ETAP AXS
• Shifter Right Description: Sram, Shift-brake lever, Rival ETAP AXS

Frame and more

• Framesize Convection: XS,S,M,L,XL
• Max loadable weight (KG): 110 kg
• Front Fork Type: Non Suspension
• Front Fork Description: Lapierre, Pulsium Disc thru axle
• Frame Description: Carbón, Hombre

Handlebar and Saddle

• Handgrip Description: Lapierre
• Handlebar Description: Lapierre, Drop bar, Alloy, Drop: 130 mm, Reach: 80 mm
• Headset Description: Acros, Integrated, AIX-532 IS52/28,6 - IS52/40
• Saddle Description: Fizik, Race, Aliante R5 150mm
• Seatpost Description: Lapierre, Non Suspension, Alloy, Ø: 27.2 mm, L: 350 mm
• Stem Description: Lapierre, internal routing, Ø: 31.8 mm, L: 80 mm

Sistema de frenos

• Brake Rear Mount: Flat Mount
• Brake Front Description: Sram, Freno de disco hidráulico, Rival ETAP AXS, 160 mm
• Brake Rear Description: Sram, Freno de disco hidráulico, Rival ETAP AXS, 140 mm

Wheels and wheel components

• Wheelset Material: Aluminio
• Tamaño de la rueda en pul: 28
• Tyre Description: Schwalbe, ONE Performance TLE, 67EPI, 28-622
• Tyre Rear Description: Schwalbe, ONE Performance TLE, 67EPI
• Wheelset Description: DT Swiss, ER1600 SPLINE 700x22c, 23mm height, AXDR driver, Centerlock
• Wheelset Rear Description: DT Swiss, ER1600 SPLINE 700x22c, 23mm height, AXDR driver, Centerlock
• Wheelsize Description: 28, 28
