Bike Geometry

• Bottom bracket drop [mm]: 67 mm,62 mm
• Chain stay length [mm]: 420 mm
• Fork offset [mm]: 505 mm
• Fork total length [mm]: 44 mm
• Head tube angle: 68 degrees
• Head tube length [mm]: 85 mm,90 mm,100 mm,110 mm
• Reach [mm]: 410 mm,435 mm,455 mm,480 mm
• Stack [mm]: 598 mm,597 mm,606 mm,616 mm
• Seat tube angle: 74 degrees
• Seat tube length [mm]: 390 mm,430 mm,470 mm,510 mm
• Top tube length [mm]: 581 mm,606 mm,629 mm,657 mm
• Wheelbase [mm]: 1086 mm,1114 mm,1138 mm,1167 mm

Drivetrain

• Cassette Teeth: 10-51T
• Crank Arm length: 170,175
• Crankset Teeth: 32T
• Crankset Type: single
• Number Of Gears: 12
• Bottom Bracket Description: Shimano, PressFit, MT800
• Cassette Description: Shimano, Cassette, Deore CS-M6100-12, MICRO SPLINE
• Chain Description: Shimano, Cadena, Deore M6100 12s
• Crankset Description: Shimano, Deore FC-MT512
• Derailleur Rear Description: Shimano, Deore 12s Shadow +
• Gear Description: Shimano, Derailleur
• Pedal Description: NW 91K Steel cage
• Shifter Right Description: Shimano, Triggershift, Deore Rapidfire SL-M6100-IR

Frame and more

• Framesize Convection: S,M,L,XL
• Max loadable weight (KG): 120 kg
• Front Fork Type: Suspension
• Suspension Type: Hardtail
• Travel Front: 100 mm
• Front Fork Description: Suntour, Raidon 32 RLR DS 15x110 29" 100 mm
• Frame Description: HIGH, Carbón, Hombre

Handlebar and Saddle

• Handlebar Diameter: 31.8 mm
• Handlebar Material: Aluminio
• Handlebar Width: 740 mm
• Seatpost Material: Aluminio
• Stem Length: 60 mm,70 mm,80 mm
• Handgrip Description: Lapierre, Anodized, small diameter
• Handlebar Description: Lapierre, Flat bar, Alloy 6061 Top flat, Ø: 31.8 mm
• Headset Description: Fsa, Integrated, IS-2 /42/ACB 1-1/8''-1.5''
• Saddle Description: Lapierre, MTB, XC Saddle
• Seatpost Description: Lapierre, Non Suspension, Alloy, Ø: 27.2 mm, L: 400 mm, 400 mm
• Stem Description: Lapierre, AL6061 Alloy, -6°, Ø: 31.8 mm, L: 60 mm

Sistema de frenos

• Brake Rear Mount: Post Mount
• Brake Front Description: Shimano, Freno de disco hidráulico, MT401 2 pistons, 180 mm
• Brake Rear Description: Shimano, Freno de disco hidráulico, MT401 2 pistons, 160 mm
• Brake Lever Description: Shimano, BL-MT401
• Brake Rotor Description: Shimano, SM-RT64 180 / 160 mm, Centerlock

Wheels and wheel components

• Tamaño de la rueda en pul: 29
• Hub Front Description: Shimano, TC500, boost 15x110, 32H Centerlock
• Hub Rear Description: Shimano, TC500, boost 12x148, 32H Centerlock, Microspline
• Rim Description: Rodi, Tryp25 25x622, 32H Black Anodized
• Rim Rear Description: Rodi, Tryp25 25x622, 32H Black Anodized
• Tyre Description: Maxxis, Rekon Race EXO TR 2.35 60 TPI
• Tyre Rear Description: Maxxis, Rekon Race EXO TR 2.35 60 TPI
• Wheelsize Description: 29, 29
