Bike Geometry

• Bottom bracket drop [mm]: 65 mm,60 mm
• Chain stay length [mm]: 428 mm
• Fork offset [mm]: 505 mm
• Fork total length [mm]: 44 mm
• Head tube angle: 69 degrees,69.5 degrees
• Head tube length [mm]: 90 mm,105 mm
• Reach [mm]: 371 mm,390 mm,416 mm,437 mm
• Stack [mm]: 584 mm,605 mm,600 mm,614 mm
• Seat tube angle: 73 degrees
• Seat tube length [mm]: 390 mm,430 mm,470 mm,510 mm
• Top tube length [mm]: 550 mm,575 mm,600 mm,625 mm
• Wheelbase [mm]: 1094 mm,1121 mm,1142 mm,1171 mm

Drivetrain

• Cassette Teeth: 10-51T
• Crank Arm length: 170,175
• Crankset Teeth: 32T
• Crankset Type: single
• Number Of Gears: 12
• Bottom Bracket Description: Shimano, PressFit, MT800 MTB 92
• Cassette Description: Shimano, Cassette, Deore CS-M6100-12, MICRO SPLINE
• Chain Description: Shimano, Cadena, Deore M6100 12s
• Crankset Description: Shimano, Deore FC-MT512
• Derailleur Rear Description: Shimano, Deore 12s Shadow +
• Gear Description: Shimano, Derailleur
• Pedal Description: NW 91K Steel cage
• Shifter Right Description: Shimano, Triggershift, Deore Rapidfire SL-M6100-IR

Frame and more

• Framesize Convection: S,M,L,XL
• Max loadable weight (KG): 120 kg
• Front Fork Type: Suspension
• Suspension Type: Hardtail
• Travel Front: 100 mm
• Front Fork Description: Suntour, Raidon 32 RLR DS 15x110 29" 100 mm
• Frame Description: HIGH, Aluminio, Hombre

Handlebar and Saddle

• Handlebar Diameter: 31.8 mm
• Handlebar Material: Aluminio
• Handlebar Width: 720 mm
• Seatpost Material: Aluminio
• Stem Length: 60 mm,70 mm,80 mm
• Handgrip Description: Lapierre, by Herrmans
• Handlebar Description: Lapierre, Flat bar, Alloy 6061 Top flat, Ø: 31.8 mm
• Headset Description: Fsa, Semi-integrated, Orbit Zero stack
• Saddle Description: Lapierre, MTB, XC Saddle
• Seatpost Description: Lapierre, Non Suspension, Alloy, Ø: 27.2 mm, L: 400 mm, 400 mm
• Stem Description: Lapierre, 7050 Alloy, 7°, Ø: 31.8 mm, L: 60 mm

Sistema de frenos

• Brake Rear Mount: Post Mount
• Brake Front Description: Shimano, Freno de disco hidráulico, MT401 2 pistons, 180 mm
• Brake Rear Description: Shimano, Freno de disco hidráulico, MT401 2 pistons, 160 mm
• Brake Lever Description: Shimano, BL-MT401
• Brake Rotor Description: Shimano, SM-RT30 180 / 160 mm, Centerlock

Wheels and wheel components

• Tamaño de la rueda en pul: 29
• Hub Front Description: Shimano, TC500, boost 15x110, 32H Centerlock
• Hub Rear Description: Shimano, TC500, boost 12x148, 32H Centerlock, Microspline
• Rim Description: Rodi, Tryp25 25x622, 32H Black Anodized
• Rim Rear Description: Rodi, Tryp25 25x622, 32H Black Anodized
• Tyre Description: Maxxis, Rekon Race 2.25 60 TPI
• Tyre Rear Description: Maxxis, Rekon Race 2.25 60 TPI
• Wheelsize Description: 29, 29
